Filter flow:15~2000 m'/h
System working pressure : 0.25-2.5Mpa
Pressure rating :1.0Mpa/1.6Mpa/2.5Mpa
Working temperature range :0~65°C
Filtering precision :50 -3000micron
Pressure loss : < 0.01 Mpa
Inlet and outlet Connection : flange
Backwash time :12~18 sec
Control mode : DP control /PLC timing control / manual
Cleaning mode : suction nozzle
Rated operating voltage :3 -ph,380v, 220v, 50Hz
